Linn Klimax Solo 800 Power Amplifier

With Klimax Solo 800, we have created a superior-performance mono amplifier which can drive any given speaker optimally – under any conditions.
To achieve this, Linn’s electronic engineers returned to first principles with their crosshairs trained on ‘consistency’ and ‘accuracy’ – because consistency and accuracy are key to pure, unadulterated, power amp performance.
It features novel and original technologies which combine to produce staggeringly low distortion measurements, with superb signal-to-noise ratio and incredible efficiency.
In a normal setup, one hears the accumulation of interactions between speaker and amp – a combination of non-ideal characteristics which result in artefacts heard in the music. Linn’s focus on relentless minimisation of distortion within the amp, and unilaterally consistent output means that Klimax Solo 800 introduces negligible harmonics or background noise to the music signal.
Two wrongs can never make a right. Klimax Solo 800, though, can do no wrong. It just – consistently – does everything right.

Power is Nothing Without Control
Klimax Solo 800 as a whole is the epitome of efficient, consistent, and accurate circuitry design.
Linn’s unique combination of digital and analogue expertise has allowed us to optimise and linearise every internal stage of the amplifier to consistently produce exceedingly high performance.

Adaptive Bias Control
Klimax Solo 800 features Linn’s original Adaptive Bias Control technology. With it, we establish the ideal bias current for each of the amp’s sixteen output transistors dynamically and in real-time by measuring, sampling and digitising the current supplied to them.
A digital control loop then implements and persistently adjusts this optimum bias current for each individual transistor specifically; negating crossover distortion at any temperature – regardless of volume or demanding dynamic changes in music – for the entirety of the amp’s life.

Cool Runnings
Klimax Solo 800 features superb heat management; driving the most difficult of loads without compromising linearity or resorting to an internal fan.
Excellent heat coupling is achieved by mounting the amplifier and power supply circuitry directly to the critically efficient, large surface area heatsinks. This cool-running design is key to delivering exceptional clarity right up to 800W into 4Ω, and 1.2kW into 2Ω.
Temperature is minimised within the amp, ensuring that the properties of its internal components remain consistent during even the loudest and most demanding passages of music. It maintains consistency, efficiency and longevity at all times.

Powered by Utopik
Linn’s all-new, Utopik switch-mode power supply topology for Klimax Solo 800 boasts precision-regulated power rails. It provides the best of both worlds, generating 2kW maximum power output whilst retaining speed, responsiveness and consummate efficiency.
It maintains extremely steady output voltage; the rails perform consistently in the face of dramatic loading changes. What’s more, if the mains input varies, the output won’t – remaining stable and ultra-pure at all times.
With Utopik for Klimax Solo 800, we have progressed a step further to minimise switching noise and improve efficiency by utilising a technique called ‘soft-switching’; a resonant tank circuit ensures that voltage across the switch falls to zero before the switch is thrown. Thanks to soft-switching, Utopik for Klimax Solo 800 is cleaner, more efficient, and remains whisper-quiet over the full range of operating conditions.

• Number of Channels: One
• Max Output: 800W into 4Ω, 400W into 8Ω, 1.2kW into 2Ω
• Amp Technology: Adaptive Bias Control
• Power Supply: Utopik (2 kW Max)
• Inputs: RCA Phono x1, Balanced XLR x1
• Passthrough: RCA Phono x1, Balanced XLR x1
• Speaker Outputs: Banana/Binding Posts x2
• Output Impedance: 0.01Ω at 1kHz, THD+N, 4 Ω 0.0005% | 1kHz | 800 W, THD+N, 8 Ω 0.0004% | 1kHz | 400 W, THD+N, 2 Ω 0.0006% | 1kHz | 1.2 kW
• Finishes: Silver or Black anodised
• Dimensions: Width 350 mm X Height 268 mm X Depth 412 mm
• Weight: 27 kg
